AC Centrifugal Fan Features:
1. Bearing System: Ball Bearing
2. Impeller: Aluminum
3. Housing: Die Casting Aluminum
4. Motor Type: Ac Brushless
5. Insulation Class: E
6. Compressive Strength: 1500v
7. Storage Temperature: -20°--- 70°
8. Working Temperature: -10°--- 60°
Specifications:
MODEL NO. | VOLTAGE (VAC) | FREQUENCY (Hz) | CURRENT (A) | POWER (W) | SPEED (RPM) | MAX AIR FLOW (CFM) | MAX PRESSURE (mm-H2O) | NOISE (dBA） |
RA-ACC280H | 230 | 50 | 1.00 | 225 | 2700 | 1242.0 | 76.00 | 75 |
230 | 50 | 0.35 | 78 | 1420 | 845.0 | 29.00 | 67 | |
RA-ACC280L | ||||||||
60 | 0.42 | 105 | 1635 | 962.0 | 21.00 | 62 |
Decription:
Ruiapple ac centrifugal fans with backward curved blades are used primarily for intake suction and do not require a scroll housing. They have high hydraulic efficiency. Both 110V or 230V are available.
Related Products:
Note: We can also adjust all the parameters according to your requirements.
